For modern manufacturers in the light gauge steel framing industry, agility and cost-effectiveness are the keys to competitiveness. The foundational C-shaped studs and U-shaped tracks are both essential, yet producing them traditionally requires separate lines or time-consuming manual changeovers. This inefficiency ends with our groundbreaking Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine. This intelligent system represents a paradigm shift in lean manufacturing, engineered to produce both critical profiles on a single, automated platform with minimal downtime. The Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine is not just a piece of equipment; it is a strategic investment designed to consolidate your production, drastically reduce operational costs, and maximize your factory's output and flexibility.
The core innovation of the Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine lies in its advanced, programmable changeover system.
decoiling→roll-forming→punching service holes→servo-driven cutting→stacking
With commands from the user-friendly touch-screen HMI, the machine can swiftly reconfigure itself—adjusting the forming rolls and cutting head—to transition from producing C-studs to U-tracks (or vice versa) in a fraction of the time required by manual systems. This seamless Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine process means you can respond instantly to project demands, producing complete framing sets just-in-time without the capital expense and floor space of two dedicated machines.
| Product Name | Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine |
| Formed Material | Steel strip |
| Machine size | 5900*900*1500mm |
| Machine weight | 2400kg |
| Thickness | 0.45-0.9mm |
| Decoiler | Manual decoiler(will give you as free) |
| Roller station | 12 rows(As your requirement) |
| Material of rollers | 45#steel, forging with chromium plate 0.05mm |
| Cutter | Cr12 Mov quenched treatment 58-60℃ |
| Power | 7.5+5.5KW |
| Control system Language | English, Spanish, etc.(Support multiple languages) |
| Voltage | 380V, 50HZ, 3Phase(customizable) |
| Forming speed | 40-50m/min(The speed depends on the shape of the tile and the thickness of the material） |
| Transmission method | Gear transmission |
| Cutting tolerance | +-1.0 mm |
The advantages of integrating this Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine into your operation are transformative. Primarily, it delivers unparalleled space and cost savings by combining two production functions into one footprint, significantly boosting your return on investment. The automated changeover minimizes non-productive downtime, ensuring optimal asset utilization. Furthermore, the machine is built for global adaptability with full customization of material width, steel thickness, voltage, and control panel language. It is also backed by comprehensive remote support, with engineers providing video guidance for maintenance and operation. Crucially, the Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine carries CE certification, guaranteeing compliance with the highest international safety and quality standards and facilitating your access to global markets.
28 years of professional R&D team
One-stop-solution for roll forming machine
Long-life stable running
High-precision finished products
High-quality raw materials
Brand electrical parts
About us
Since 1996 year, Promax Group main products have evolved from a standard keel roll forming machine to a customized automated high speed keel roll forming equipment production line, cooperating with 150+ countries & 5,000 + partners，always adhering to the concept of "honesty is our aim, win win is our pursuit", insisting on the service principles of "customer first, quality first, service first, after sales first", efficiently and professionally complete the products required by customers.
Q: Are you a trading company or a factory?
A: We are a factory with a professional production team and service consciousness, just for exporting various types of cold roll forming machines.
Q: Can a machine produce only one style of panel profile?
A: Not complete. Suitable for a Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine. It can produce more than 3 panels.
Q: How long does it take to manufacture the machine?
A: In general, the Fully Automatic C/U Changeover Metal Stud and Track Roll Forming Machine can be completed in 20 to 45 business days. But if you need machines urgently, we can save you time.
Q: Is there quality control when producing the production line?
A: Yes, we have a team that is responsible for quality control, including the laying of raw materials, processing rolls and other parts, processing, assembly, testing, and packaging on the roll surface and shaft.
Q: What can you do if the machine breaks?
A: Our machine is warranted for 24 months. If the damaged part cannot be repaired, we can send a new part to replace the damaged part, but you will need to pay the courier fee yourself. If the warranty period is exceeded, we can resolve the issue through negotiation, and we provide technical support for the entire life cycle of the device.
